240*320 2.58” AMOLED Display DG-258DN01
Diagonal Size: 2.58’’
Resolution: 240*320 RGB
Pixel Pitch: 0.056*0.168 mm
Active Area: 39.6*52.48 mm
Module Size: 44.48*62.35 mm
Brightness: 200cd/m2
Thickness: 1.7Typ mm
Voltage: 3.3V
Operating Temp: -30 to 80°C
Storage Temp: -40 to 90°C
Color Mode: Full Color (16.7M Color)
Driving Mode: Active Matrix
